Title

ANÁLISE DA VIABILIDADE DE SEPARAÇÃO E CONCENTRAÇÃO DE FINOS DE CARVÃO DO PÓ DE BALÃO

ANALYSIS OF VIABILITY OF SEPARATION AND CONCENTRATION OF COAL FINES FROM OFF GASES DUST

DOI

10.5151/2594-357X-30468

Downloads

877 Downloads

Abstract

O presente trabalho objetiva analisar a viabilidade técnica de recuperar parte do pó de balão, composto por finos de carvão e hematita, submetido primeiramente a tratamento termoquímico e posteriormente a campo magnético uniforme. Foram analisadas amostras oriundas de pó de balão de alto forno funcionando com carvão mineral e alto forno com carvão vegetal. Os finos de carvão, recuperados na separação magnética, podem ser utilizados na sinterização, pelotização e até mesmo reinjetados nas ventaneiras. Essa reutilização tem um efeito muito importante, pois cada tonelada de fino carregado pela ventaneira corresponde a uma economia de carvão que não será carregado pelo topo, deixando mais volume útil livre para a carga de minério. O pó de balão foi submetido a um processo de redução da hematita em magnetita, em atmosfera adequada para a preservação de carbono, a fim de aumentar a susceptibilidade magnética e permitir a separação magnética. Os finos de minério residuais da recuperação dos finos de carvão não são perdidos, podem ser utilizados na fabricação de briquetes ou reutilizado na sinterização e pelotização. Após a redução, o material foi submetido à separação magnética, mostrando-se assim viável tecnicamente a separação e reaproveitamento dos finos de carvão e minério.



The present work had as objective to analyze the technical viability of recovering part of the off gases dust, composed of coal fines and hematite fines, when first submitted to thermochemical treatment and later to uniform magnetic field. Samples of off gases dust were analyzed from blast furnace running with coal and blast furnace with charcoal. Coal fines, recovered in the magnetic separation process, can be redirected to the sintering, pelletizing and even reinjected in the blast furnace. This re-use has a very important effect because each tone of fine charged by the injection at furnace blast corresponds to an equal or greater weight of coal that will not be charged from the top, leaving more useful volume free for the ore load. The off gases dust was subjected to a process of reduction of the hematite in magnetite, in an atmosphere suitable for the preservation of carbon, in order to increase the magnetic susceptibility and allow the magnetic separation. The residual ore fines from the recovery of coal fines are not lost, it can be used in the manufacture of briquettes or reused in sintering and pelletizing. After the reduction, the material was subjected to magnetic separation, thus it was technically viable to separate and reuse the fines from coal and ore.

Keywords

Redução, Pó de balão, Finos de carvão

Reduction, Gas off dust, Coal fines

How to refer

Santos, Alisson Rodrigo dos; Araújo, Fernando Gabriel da Silva; Souza, Erivelto Luís de; Solé, Rubén Antônio Llobell. ANÁLISE DA VIABILIDADE DE SEPARAÇÃO E CONCENTRAÇÃO DE FINOS DE CARVÃO DO PÓ DE BALÃO , p. 93-104. In: 47º Seminário de Redução de Minérios e Matérias-Primas, São Paulo, 2017.
ISSN: 2594-357X , DOI 10.5151/2594-357X-30468
